Large Image :  Concrete Hybrid Mortar Epoxy Sleeve Anchors With Injection Guns

Product Details:
Place of Origin: China
Brand Name: XINCHOR
Model Number: FixingChor 158
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: individual in plastic cartridges, 20pcs/ctn,
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 100,000pcs per month
Detailed Product Description
Materials: Epoxy Initial Curing: 30 Mins Under 25 Degree Celsius
Color: Grey Or Red Weight: 1020g
Mixing Ratio: 3:1 Capacity: 585ml
Tensile Strength: 55KN
High Light:

Hybrid Mortar Epoxy Sleeve Anchors


Concrete Epoxy Sleeve Anchors


Injection Guns Concrete Anchor Epoxy

Fast Setting Epoxy Sleeve Anchors Hybrid Mortar No Hole Cleaning Required


▪Excellent mortar bonding ensures highest loads in


▪Suitable for underwater installations.

▪Suitable for diamond drilled holes.

▪Expansion-free anchoring allows low axial spacings and

edge distances.

▪Ergonomic injection guns for quick and easy installation


Approved for anchorings in:

Concrete,cracked and non-cracked Applications

Rebar planting in concrete structures.

Structure reinforcement

Curtain wall installing

Bridge modification works

Keel fixing in out wall

Railway or express way modification works



Pass GB50728-2011

Humidity resistance testing

Freeze-thaw resistance Testing

Resistance to fatigue stress Testing

Resistance of long term stress testing etc .

Can be used in projects with Design Period of 50 years.



Non-cracked concrete

Can use in damp area

High load capacity

Non-sag, even overhead


Low odour

Non contraction after harden

High stability

No transportation restrictions


High bonding strength,

Can be applied in severe environment

With molecular structure combining the Hydrophilic group and hydrophobic group

Can operate and keep high performance in environment of moisture, hot and still

works even if the surface of hole is smooth.

Technical Parameter:


1. Basic parameters

1) Appearence

Part A (main): white cream

Part B (hardener): red cream  / grey  cream

2) Mixed Viscosity: 18-22 Pa.s

3) Hardened density: 1.50 ± 0.10g/cm3

4) Mixing ratio (Volume ratio):  585ml  (3:1)

5) Shelf time: 24 months


2 Main Performance

Testing project Condition Index
Gel Performance  (According to China National Standard GB50728-2011)
Split Tensile Strength (MPa) Under (23±2)℃, (50±5)%RH, tested by loading speed of 2mm/min ≥8.5
Flexural Strength (MPa)


(no fragment damage)

Compressive Strength (MPa) ≥60
Bonding Capacity (According to China National Standard GB50728-2011)
Steel-Steel Tensile Shear Strength (MPa) (23±2)℃  (50±5)%RH ≥10
Bonding strength of Ribbed steel bar (or screw) with concrete under constrain drawing condition (23±2)℃ (50±5)%RH C30,Ф25,L=150mm ≥11
C60,Ф25,L=150mm ≥17
Steel-Steel  T-peeling strength (mm) (23±2)℃,(50±5)%RH ≤25
Non-volatile content (105±2)℃,(180±5)min ≥99%
Ageing resistance to heat and humidity 90d
Reduction rate of tensile strength Under normal room temperature ≤12%
 (According to China National Standard JGJ145-2013)
Tensile  Strength (after high temperature welding)

Dia12 Grade II steel, C30 concrete

Hole dia.16mm, Depth: 150mm

55.1N, 57.0N, 54.8N

3 Technical Data

Anchoring Adhesive used with thread rod

Thread Rod Dia


C30 Concrete

M10 M12 M16 M20 M24
Drilling Dia.(mm)   12 14 18 24 28
Depth (mm)   90 110 145 180 220
Damage Pulling force KN Grade 5.8 Steel 29 42.2 78.5 122.5 254.5
Grade 8.8 Steel / A4 SS 36.8 52.9 94.1 147.0 211.7
Damage Cutting force  KN Grade 5.8 Steel 17.4 25.3 47.1 73.5 105.9
Grade 8.8 Steel `27.8 40.5 75.3 117.6 169.4
Designed Pulling force  KN   12.0 17.02 30.6 52.4 75.2
Designed Cutting Force  KN Grade 5.8 Steel 12.2 17.6 32.9 51.5 74.1
Grade 8.8 Steel 18.6 27.0 50.2 78.4 113.0
Holes for each   54 25 8 5 3


Best performance mortar in the shuttle cartridge based on

epoxy resin.

▪ Optimum solution for concrete (anchor rods and reinforcement bars).

▪ Resin and hardener are stored in two separate chambers

and are not mixed and activated until pushed through the static mixer.

▪ Partially used cartridges can easily be reused by changing the static mixer.




Use in extremely cold environments and fixings holes.

Fast working times for early loading in time sensitive applications.

Good durability formulation, resistance to chemicals.

Used for studs and relatively small diameter rebar. ⋅

Fixings in concrete, wood, or other high strength materials.

Suitable for medium loads and non-critical applications.


Curing time:


Operation and Curing time
Temperarure -5 0 10 20 ≥30
Operation time (min) 60 45 30 25 20
Curing time (h) 72 48 24 12 6



Consumption Chart (holes per cartridge)


Anchor Rod dia. M10 M12 M16 M20 M24
Drilling Dia.(mm) 12 14 18 24 28
Depth (mm) 90 110 145 180 220
Each usage 8ml 13ml 28ml 62ml 103ml
360ml 45 27
390ml 48 30 14 6 3
585ml 73 45 20 9 5
650ml 81 50 23 10 6
